100% NEW CARB TURNKEY
All LowBugget Engines are 100% NEW, Not a few new parts.... 100% NEW!!!
All combos are made to order for you!!
This means we make the perfect engine for you and your needs!
You have a lot of options and we have a lot of answers, So give us a call.
Built to last and drive daily "hard"!
Ask about our FREE shipping Crate!
The long block for our turnkey come standard with:
OEM Magnesium AS41 case.(larger engine combos will come standard with Aluminum case.)
Each case is Spot Faced, Full Flowed and hand clearance,
8 dowel chromoly 4340 crankshaft that is nitrided for added strength, micro polished, and dynamically balanced.
12v flywheel 4130 1-piece chromoloy made strong but light at 13lbs or stock, call for info.
Straight cut "No thrust load" cam gears.
High lift billet 1.25 or 1.4 rockers with solid shafts, swivel adjusters, and 4130 studs.
USA made Manton 3/8" Seamless 4140 .058" thick chromoly push rods.
"I" Beam chromoly rods with real USA Made ARP 8740 rod bolts. (larger combos come standard with "H"- Beam)
Balanced piston with hand honed barrels for fast ring seating.
Hard and lightweight USA Made billet lifters that are parkerized coated to help with brake-in.
Chromoly 4130 gland nut to hold it all together tight.
A.J.Sims Builders Prep 100,000 mile hand built heads, LowBugget Exclusive
Chromoly 8 or 10mm head studs.
Deep sump for extra oil capacity
HD 30mm oil pumps with full flow cover.
Polished Aluminum bolt on or clip on valve covers.
And more!!!
List of external parts on our turnkey engine combos:
Billet pulley, you pick the color. Red, Blue or Black
Powder Coated Fan Shroud and Cylinder Covers, You pick the color Black, Red or Porsche Silver
Dog-house oil cooler and mounting stand kit.
LowBugget.com 40mm pre-set and jetted complete Kadron carb kit with our curved in house CVD vacuum distributor kit.
MSD-Billet pointless ignition.
NGK spark plugs
MSD performance long lasting wires.
You pick the Coated style you like. Polished Ceramic or Black Ceramic header and muffler.
High out-put 55amp Alternator
Stage 1 or 2 pressure plate and Exedy performance street clutch disc kit.
This is a complete motor. Just add oil and your on your way!!
Please note that hp and tq ratings is based on "real" pump gas (91octane) daily driver combos.
We can change cam,compression, exhaust, heads and carbs to get more HP if you like.
1600cc 69mm x 85.5mm
Carb Turnkey dual 40mm carbs, 1 3/8" ceramic header and muffler (55hp)
12 month / 10,000 mile warranty
1641cc 69mm x 87mm
Carb Turnkey dual 40mm carbs, 1 3/8" ceramic header and muffler (65hp)
1776cc 69mm x 90.5mm
Carb Turnkey dual 40mm carbs, 1 3/8"ceramic header and muffler (75hp)
12 month / 12,000 mile warranty
1835cc 69mm x 92mm
Carb Turnkey dual 40mm carbs, 1 3/8" ceramic header and muffler (85hp)
1915cc 69mm x 94mm
Carb Turnkey dual 40mm carbs, 1 1/2" ceramic header and muffler (95hp)
2007cc 78mm x 90.5mm
Carb Turnkey dual 40mm carbs, 1 1/2" ceramic header and muffler, I-Beam rods, Aluminum Super Case (115hp/120tq
reliably)
2110cc 82mm x 90.5mm
Carb Turnkey dual 40mm carbs, 1 1/2"ceramic header and muffler,I-Beam rods, Aluminum Super Case (130hp/140tq
reliably)
2165cc 78mm x 94mm
Carb Turnkey dual 44mm carb, 1 5/8" ceramic header and muffler,H-Beam rods, Aluminum Super Case (135hp/145tq
reliably)
2276cc 82mm x 94mm
Carb Turnkey dual 44mm carb, 1 5/8"ceramic header and muffler,H-Beam rods, Aluminum Super Case
2332cc 84mm x 94mm
Carb Turnkey 44mm Dual IDF carb kit, 1 3/4"ceramic header and muffler,H-Beam rods, Aluminum Super Case
2387cc 86mm x 94mm
Carb Turnkey dual 48mm carb, 1 5/8"ceramic header and muffler, H-Beam rods, Aluminum Super Case
2442cc 88mm x 94mm
Carb Turnkey dual 48mm IDA's, MSD, 1 3/4"ceramic header and muffler,H-Beam rods, Aluminum Super Case
2498cc 90mm x 94mm
Carb Turnkey dual 52mm IDA's, MSD, 1 3/4"ceramic header and muffler,H-Beam rods, Aluminum Super Case
Wiseco pistons, 44x37 CNC heads
Some of the options:
Change to our Fuel Injection. Add $Call
Change to 911 shroud kit in Red, Black, Silver or Blue add
Wiseco forged pistons with machined to size mahle barrels add
Total Seal seconds set rings add $Call
Total Seal Complete Ring Set add $Call
Change to CNC 40x35.5mm heads add
Change to Weber 51mm IDA with Jay-Cee stacks add $Call
Change over to Flanged 84mm or 86mm Crank (only available on aluminum case combos) add $Call
Shipping crate fee
We will not ship your new engine just strapped to a pallet like other shops.
We will only ship our engines in a crate. This way your new engine can be insured 100%.
Long Block crate fee $Call, Turn Key crate fee $Call, Turn Key engine and Transmission crate FREE
Need a transmission for your new engine!!! Click here
Get FREE shipping Crate when you order a engine and transmission together!
That saves you!
All of our Turnkey engines include our 12 Start Brake-in FREE!
This includes oil pressure checking before start-up, False load cam and lifter brake-in,
minimum of x12 200* degree cylinder temp heat cycles. We will adjust the idle speed, fuel mixture
setting and timing. After each 200* degree test run, we place a fan on the motor to cool it quickly.
This will help us to detect any oil leaks or possible problems.
We drain the motor of all its used oil and external oil filter. Next we will remove the rocker assembly
and re-torque the heads to spec, reassemble the rockers and adjust the valves and it is ready to go.
All of our engines also include complete dyno service on our 800hp digital Dyno FREE!
It will include the 12 Start Brake-In plus a complete Dyno session to find out what your beast makes.
We will do all the jetting and set up at this time as we can now place your combo under a full load.
We don't just make some max hp pull at a set rpm,
We will take your combo from 3,000 rpms to 6,000 rpms in 250 to 500rpm steps.
We then do it all over to back up all the numbers.
Placing your combo on the dyno is the best way to find if there is a problem.
Oil psi, oil temp, boost psi, vac Hg", AF ratio, cylinder temp, head temp, exhaust temp, RPM, HP and TQ numbers are
all given.
You have Questions? We have Answers!
Call for info!!
714-639-4284
M-F 9 to 6pm Sat 10am to 3pm
We Ship World Wide!!
Page last update 8-4-23
|
